Understanding Rigid Sleeve Couplings

A lot goes on behind the scenes to ensure seamless torque transmission. Gears and splined shafts are known for their contribution to torque transmission, and rightly so. However, gear and sleeve couplings don’t get the credit they deserve.



Their contribution goes unnoticed by many. Flexible and rigid sleeve couplings are used to fix misalignment between two rotating shafts. In this blog, we discuss rigid sleeve couplings in particular.



We at True Gear & Spline Ltd. have decades of experience manufacturing and supplying custom sleeve couplings, gears, and splined shafts to clients in Ontario.





What Is A Rigid Sleeve Coupling?



A rigid sleeve coupling is designed for two rotating shafts that are perfectly aligned. The primary task of a rigid sleeve coupling is the transfer of torque from the driver shaft to the driven shaft.



Its simple “clamp-on” mechanism makes installation very easy. One of the best things about rigid sleeve coupling is that it does not require lubrication. Rigid couplings are most suitable for medium- to high-torque and low-speed applications.



Thanks to the rigidity, this coupling transmits power effortlessly. However, the lack of flexibility means it cannot accommodate misalignments.





The Types of Rigid Sleeve Coupling



There are primarily two main types of rigid sleeve couplings. Let’s take a look at them without further ado.



Solid Sleeve Coupling

Also known as muff couplings, solid sleeve couplings are secured around the intersection of two shafts using keys and screws. It is a cylindrical sleeve without any frills or unwanted components. Minimal moving parts ensure longevity.



Split Sleeve Coupling

Also known as the split muff coupling, it features two halves, as opposed to the single sleeve of solid sleeve couplings. One of the best things about split-sleeve couplings is the ability to be bolted around the shafts without moving the machines. This coupling is ideal for applications where space is limited.





Conclusion

No matter what your design and application requirements are, we at True Gear & Spline Ltd. can manufacture the best rigid sleeve couplings. Our design and engineering team boast decades of collection experience. Our state-of-the-art facility is equipped with the latest tools and equipment for manufacturing torque transmission components. Call 519-653-1301 to get a free quote today.





FAQs



What is a rigid sleeve coupling used for?

A rigid sleeve coupling is used to connect two perfectly aligned shafts. It helps transfer torque from the driver shaft to the driven shaft.



What are the two types of rigid sleeve couplings?

Solid sleeve coupling and split sleeve coupling are the two types of rigid sleeve coupling.



Where can I get the best rigid sleeve coupling in Toronto?

True Gear & Spline Ltd. in Cambridge, Ontario, custom manufactures the best rigid sleeve coupling. We supply our products to clients across Toronto and the GTA.
